Description
Accurate constant circuit drive develops excellent performance of LED
Using high power LED, high efficacy and long service life
Improve performance of camera to get better pictures at night time
Fill Light for night vision camera
Indoor/Our door use
Easy installation



Specification
Quantity of LED                4PCS 2W High Power LED
Wavelength                      850nm
Power Factor                    0.9-0.98
Bean Angle                       15°/30°/45°/60°/90°
Viewing Distance              100~10m
Day/night Switch               Auto
Working Voltage               AC110-220V/AC24V/DC12V
Power consumption          12W
Wire                                  If 12VDC/24VAC:45cm(1.4 ft.)
Plug                                  AC110-220V (standard), other voltage optional
Panel                                Tempered glass panel
Housing                            Aluminum Die Casting Housing
Bracket                             Mount bracket
Working temperature       -25°C TO +50°C
Protection Level                IP65
Color                                 Gray
Panel                                Glass Panel
Housing                             Aluminium Die-casting Housing
N.W                                  0.6KG
G.W                                  0.8KG
Dimension                         114*86*86mm
Packing Dimension            160*150*135mm



Model                Bean Angle        Viewing distance
ST-L4N-15-IR         15°                   100m
ST-L4N-30-IR         30°                   80m
ST-L4N-45-IR         45°                   60m
ST-L4N-60-IR         60°                   40m
ST-L4N-90-IR         90°                   10m



Viewing distance is tested by Watec/WAT-902H 1/3" CCD Camera.

To achieve the distance needed, please pay attention to your camera specification

and lens before purchase. It is normal phenomenon that distance may vary due to
